MRCOOL VersaPro 5 Ton Horizontal Package Heat Pump - R-454B

Description

MRCOOL VersaPro® 60,000 BTU 5 Ton 13.4 SEER2 Horizontal Packaged Heat Pump – R-454B

The MRCOOL VersaPro® 60K Horizontal Packaged Heat Pump is a powerful, all-in-one HVAC system engineered to deliver dependable year-round comfort for larger homes and demanding applications. Designed to handle high-capacity heating and cooling needs, this unit provides consistent performance through hot summers and cold winter conditions while maintaining energy efficiency. With a 13.4 SEER2 rating, the VersaPro® 60K helps reduce overall energy consumption and operating costs without sacrificing output. Utilizing environmentally responsible R-454B refrigerant, it supports modern efficiency standards with a significantly lower global warming potential than legacy refrigerants, making it a smart choice for eco-conscious upgrades.

Built for durability and long service life, the VersaPro® 60K features a power-painted galvanized steel cabinet that protects internal components from weather exposure, corrosion, and wear. Its horizontal discharge design promotes quieter operation, making it suitable for residential installations where noise control is important. Internally, aluminum tubing and fin coils enhance heat transfer efficiency while offering superior corrosion resistance compared to copper, reducing maintenance and extending system lifespan. A high-efficiency scroll compressor paired with an ECM blower motor delivers precise airflow control, balanced temperature regulation, and reduced energy usage. Integrated safety protections help guard against abnormal pressure and coil temperature conditions. Backed by a 10-year parts warranty and 10-year compressor warranty with registration, the MRCOOL VersaPro® 60K provides long-term reliability, energy savings, and peace of mind.

Features

• 60,000 BTU (5 Ton) horizontal packaged heat pump

• All-in-one packaged design for simplified installation

• 13.4 SEER2 efficiency for improved energy savings

• Eco-friendly R-454B refrigerant with reduced environmental impact

• Durable power-painted galvanized steel cabinet

• Horizontal discharge design for quieter residential operation

• Aluminum tubing and fin coils for improved heat transfer and corrosion resistance

• High-efficiency scroll compressor for reliable performance

• ECM blower motor with multiple speed settings

• Built-in safety protections for pressure and temperature control

• Compatible with standard 24V thermostats

• Optional auxiliary electric heat kits available

• AHRI certified and UL / CSA / ETL listed

Specifications

• Model / SKU: MPH601HO13C

• Unit Type: Packaged Heat Pump

• Tonnage: 5

• Cooling Capacity: 56,500 BTU

• Heating Capacity: 56,000 BTU

• SEER2: 13.4

• EER2: 11

• HSPF2-4: 6.7

• Airflow: 1,750 CFM

• Voltage: 208/230V

• Phase: Single Phase

• Frequency: 60 Hz

• Refrigerant Type: R-454B

• Refrigerant Charge: 95 oz

• Compressor Type: Scroll

• Metering Device: Piston

• Blower Motor: ECM, 3 Speeds

• Max Fuse Breaker: 60A

• Min Circuit Ampacity: 48.6A

• Sound Level: 81 dBA

• Minimum Ambient Cooling: 32°F

• Minimum Ambient Heating: −0.4°F

• Auxiliary Heat: Optional (5kW, 7.5kW, 10kW, 15kW, 20kW)

• Certifications: AHRI, UL, CSA, ETL

• Warranty:

  • Registered: 10-Year Parts / 10-Year Compressor

  • Base: 5-Year Parts / 5-Year Compressor

What’s Included

• MRCOOL VersaPro® 60K Horizontal Packaged Heat Pump

  • Model / SKU: MPH601HO13C

• Factory-installed compressor, blower, and controls

• Installation and operation documentation

Manuals & Downloads

INSTALL MANUAL

SPECS

SERVICE MANUAL

WARRANTY DOC
